Heat Pump Specifications

Platinum 18 Heat Pump With American Standard® Link

4a6v8

The Platinum 18 AccuComfort™ variable speed system is one of the industry’s most reliable and cost-effective heat pump units with ratings up to 18.00 SEER2/8.50 HSPF2. Available in 2-, 3-, 4- and 5-ton models, this unit features a woven Spine Fin™ coil, Duration™ Variable Speed inverter-driven compressor, and is compatible with our American Standard Link® communicating technology.

Up To 18.00 SEER2/8.50 HSPF2

• American Standard Link connectivity
• 2, 3, 4 and 5 ton
• Woven Spine Fin™ coil
• Variable-speed fan motor
• Swept fan blade
• Compressor sound insulator
• Duration™ Variable Speed inverter compressor
• Four-wire connections with optional three-wire configuration
• ENERGY STAR® qualified system ratings available for select models

Platinum 17 Heat Pump With American Standard® Link

4A6V7

The Platinum 17 AccuComfort™ variable speed system is one of the industry’s most reliable and cost-effective heat pump units with ratings up to 17.00 SEER2/8.50 HSPF2. Available in 2-, 3-, 4- and 5-ton models, this unit features a woven Spine Fin™ coil, Duration™ Variable Speed inverter-driven compressor, and is compatible with our American Standard Link® communicating technology.

Up To 17.00 SEER2/8.50 HSPF2

• American Standard Link connectivity
• 2, 3, 4 and 5 ton
• Woven Spine Fin™ coil
• Variable-speed fan motor
• Swept fan blade
• Compressor sound insulator
• Duration™ Variable Speed inverter compressor
• Four-wire connections with optional three-wire configuration
• ENERGY STAR® qualified system ratings available for select models

Platinum 19 Side Discharge

4A6L9

The Platinum 19 AccuComfort™ variable speed, side discharge heat pump with ratings up to 19.00 SEER2/9.00 HSPF2. Available in 2-, 3-, 4- and 5-ton models, this unit was designed to meet the dimensional requirements for Zero Lot line applications and features a Duration™ Variable Speed inverter-driven compressor, a swept fan blade, and AccuLink™ capability for industry leading efficiency and performance.

Up To 19.00 SEER2/9.00 HSPF2

• Low Profile
• 2, 3, 4 & 5 ton
• Variable-speed fan motor
• Swept fan blade
• Compressor sound insulator
• Copper tube aluminum fin coil
• Duration™ Variable Speed inverter compressor
• AccuLink™ capability
• Two-wire connections

Gold 16

4A6H6

The two-stage Gold 16 heat pump offers up to 16.20 SEER2/8.10 HSPF2 making it an energy-efficient choice for home comfort. Available in 2, 3, 4, and 5-ton models, this unit features a Spine Fin™ coil and a two-stage Duration™ compressor to handle any outdoor climate conditions and prevent interior temperature swings.

Up To 16.20 SEER2/8.10 HSPF2

• 2, 3, 4 and 5 ton
• Spine Fin™ coil
• 2-stage Duration™ compressor
• ENERGY STAR® qualified system ratings available for select models

Silver 15

4A6H5

The single-stage Silver 15 heat pump offers up to 15.60 SEER2/8.10 HSPF2 making it an energy-efficient choice for home comfort. Available in 1.5-5 ton models, this unit features a Spine Fin™ coil and a Duration™ compressor to handle any outdoor climate conditions and prevent interior temperature swings.

Up To 15.60 SEER2/8.10 HSPF2

• 1.5–5 ton
• Spine Fin™ coil
• Duration™ compressor for (select models)
• ENERGY STAR® qualified system ratings available for select models

Silver 15 Side Discharge

4A6L5

The single-stage Silver 15 Side Discharge heat pump boasts an industry-leading efficiency of up to 15.60 SEER2/8 HSPF2, with quieter running sound as low as 69 dBA. Available in 2-4 ton models, making it an energy-efficient choice for home comfort.

Up To 15.60 SEER2/8 HSPF2

• 2–4 ton
• Copper tube aluminum fin coil
• Duration™ compressor
• Sound levels as low as 69dBA

Silver 14

4A6H4

The single-stage Silver 14 heat pump offers up to 14.80 SEER2/7.80 HSPF2 making it an energy-efficient choice for home comfort. Available in 1.5 – 5-ton models, this unit’s Spine Fin™ coil and a Duration™ compressor can handle outdoor climate conditions and prevent interior temperature swings.

Up To 14.80 SEER2/7.80 HSPF2

• 1.5 – 5 ton
• Spine Fin™ coil
• Duration™ compressor
• Compressor sound insulator (select models)

Gold 17 3-Phase

4A7C7

The two-stage Gold 17 heat pump offers up to 17.50 SEER/9.6 HSPF making it an energy-efficient choice for home comfort. Available in 3, 4, and 5-ton models, this unit’s Spine Fin™ coil and a two-stage Duration™ compressor handle any outdoor climate conditions and prevent interior temperature swings.

Up To 17.50 SEER/9.60 HSPF

• 3-Phase
• 3, 4 and 5 ton
• Spine Fin™ coil
• 2-stage Duration™ compressor

Silver 14 3-Phasecomplement

4A7C4

The single-stage Silver 14 heat pump offers up to 15.50 SEER/9.50 HSPF making it an energy-efficient choice for home comfort. Available in 3-, 3.5-, 4- and 5-ton models, this unit features a Spine Fin™ coil to handle any outdoor climate conditions and prevent interior temperature swings.

Up To 15.50 SEER/9.50 HSPF

• 3-Phase
• 3, 3.5, 4 and 5 ton
• Spine Fin™ coil
• Duration™ compressor
